What should bandage packaging protect and communicate?
A carton must keep the packed bandages in order and tell a shopper what is inside before it is opened. A carton can hold one retail unit, separate assorted sizes, act as an outer pack for pouches, or fit a small dispenser. Write down the bandage count, wrapper shape, opening method, and where the package will sit, on a shelf, inside a mailer, or in a kit, before choosing the structure.
SBS means solid bleached sulfate paperboard, while C1S means coated on one side. Both are common when the printed face needs a clean surface. Typical industry stock is 12 to 24 pt, and the choice changes with panel size, pack weight, folds, and handling. Kraft board at 18 to 24 pt has a different surface and visual direction. These are typical material ranges, not an order promise.
Which box structures fit bandage products?
The closure changes the packing motion, so a tuck carton and an auto-lock bottom should not be treated as the same job. FEFCO 0427 is a standard code for a roll-end tuck-top corrugated mailer.
| Structure | Useful when | Packaging consideration |
|---|---|---|
| Straight tuck end | Compact retail carton | Top and bottom tuck panels support repeat opening |
| Reverse tuck end | Panel orientation or seam placement matters | Opposing tuck directions can help the dieline fit the artwork |
| Auto-lock bottom | Hand packing needs a formed base | Locking panels reduce separate base assembly |
| Mailer | The package also ships or holds a kit | Roll end tuck top or FEFCO 0427-style structure adds a defined closure |
A straight tuck end keeps the retail opening familiar. A reverse tuck end can move the seam away from a front panel. An auto-lock bottom changes how the blank is folded and loaded. For several bandage formats, a sleeve or mailer can hold an inner arrangement instead of giving every pouch its own carton. Check glue tabs, scores, and clearances with a folded sample.
How should bandage packaging be sized?
Inside length x width x depth is the working size for the packed bandage, not the outside face. Start with the actual wrapper and count, then allow room for a divider, insert, or dispenser wall. About 1/16 in (1.5 mm) is a common packaging planning tolerance, but the sample decides whether the fit works. The production clock starts after proof approval, not when the order is first discussed.
PET means polyethylene terephthalate, a clear film commonly used for a window. PET window film around 0.2 to 0.3 mm is a common industry reference. Window patching adds a converting step, and the cutout should stay clear of glue flaps and critical crease lines. If the bandages do not need to be seen, a fully printed panel leaves more room for instructions, count, and product identification.
Which print and finish choices help at shelf distance?
Offset CMYK uses cyan, magenta, yellow, and black to carry detailed paperboard artwork, while digital print can fit a short run or an early packaging test. Matte or gloss lamination changes the surface and how light breaks across the panel. Soft-touch adds a smoother feel. Spot UV puts a hard glossy area over selected art, but it deserves a fold check because coatings can crack along scores. Foil stamping, embossing, and debossing need the same check around small type and crease lines.
Put product type first, size or use second, and count or assortment details in a consistent location. Bleed is artwork that extends past the cut line. Leave it outside the cut line, keep type away from scores and glue areas, and ask for a press check that looks at color registration, solid ink coverage, and barcode contrast. Compare the construction in perforated packaging, private label packaging, and wax packaging. The broader artwork route is in custom packaging design.
What should I confirm before ordering bandage packaging?
A packed sample is the fastest way to catch a wrapper that jams a tuck flap or a divider that leaves the contents loose.
- Confirm the packed product dimensions, count, orientation, and any insert requirement.
- Choose paperboard, kraft, or a windowed format based on protection and visibility.
- Check creases, glue flaps, opening sequence, print coverage, and finish samples.
- Approve the dieline and proof only after checking copy, barcodes, and panel order.
Custom Packaging Lane quotes bandage packaging from a 100-unit minimum, with pricing from $0.49 per unit at volume, quoted to spec. Production is typically 8 to 10 business days after proof approval, plus delivery. Free US shipping, free design support, and a free dieline are available. The $19.99 sample kit is credited to the first order. Order the sample kit before approving board, structure, and finish.
Frequently Asked Questions
What paperboard thickness is common for a bandage carton?
Bandage cartons commonly use SBS or C1S paperboard in the 12 to 24 pt range. SBS is solid bleached sulfate, while C1S is coated on one side. Kraft board in the 18 to 24 pt range gives a different surface and visual direction. The final caliper depends on panel size, pack weight, folds, and handling.
When does a PET window make sense for bandage packaging?
A PET window makes sense when the wrapped bandage or pouch needs to be seen before opening. PET, polyethylene terephthalate, is commonly used as clear window film, with 0.2 to 0.3 mm a common reference range. Keep the cutout away from glue flaps and crease lines, and check the loaded carton because patching changes the converting step.
What is FEFCO 0427 used for?
FEFCO 0427 is a standard code for a roll-end tuck-top corrugated mailer. In a bandage package, that structure fits a format that needs a defined closure and some shipping orientation. Check the mailer with the actual pouch, dispenser, or kit inside, since folds, glue areas, and clearance determine whether the closure works.
Should bandage packaging use matte or gloss lamination?
Matte lamination reduces surface shine and gives the carton a softer visual read, while gloss lamination reflects more light and can make printed color appear brighter. Spot UV adds a hard glossy area to selected artwork. Check any coating across scores and folds, and keep small instructions and barcodes on a flat, readable panel.
What does a loaded bandage sample reveal?
A loaded bandage sample reveals whether the wrapper, count, divider, or dispenser actually fits the carton. It also exposes a tuck flap that catches, a window that misses the product, copy placed over a fold, or a barcode that loses contrast. Load the same arrangement planned for the order, then handle the closed pack before final approval.
