A pendant box has to hold the jewelry in a repeatable position and show the intended face when the lid opens. A dieline is the flat cutting template used to print and cut the package. Start it from the loaded pendant, chain, clasp, backing card, and insert, not from a generic jewelry-box label.
What should fit inside a pendant box?
The loaded reference must show the pendant, chain, clasp, backing card, and insert together. State which face should greet the buyer and whether the chain follows a channel, rests behind a card, or occupies a separate area. The insert belongs in the first structure discussion because it controls the cavity, loading step, and visible reveal.
Which pendant box structure should I choose?
A two-piece rigid box lifts its lid from a base, while a magnetic flap keeps the closure attached to the box. A drawer or slide moves an inner tray through an outer sleeve. A folding carton ships flat and uses a straight tuck end or reverse tuck end construction.
| Structure | Construction reference | Jewelry question |
|---|---|---|
| Two-piece rigid | Separate base and lid with an internal insert | Should the lid lift away from the pendant reveal? |
| Magnetic flap | Hinged presentation box with a closing flap | Where should the flap and brand mark sit? |
| Drawer or slide | Outer sleeve with a moving inner tray | How should the tray expose the pendant and card? |
| Folding carton | Straight tuck end or reverse tuck end paperboard box | Can it ship flat and retain the insert? |
What materials work for a pendant box?
Rigid chipboard holds its shape because the 1.5 to 3 mm board is wrapped in 100 to 157 gsm art paper. SBS, C1S, or C2S paperboard from 12 to 24 pt can support a folding carton or sleeve. Kraft board around 18 to 24 pt gives another surface direction. The pendant, chain, insert, opening, storage path, print coverage, and hand feel should drive the material choice.
How should the insert hold the jewelry?
The insert needs a defined pendant cavity and a chain route that stays clear of the clasp. Foam, paperboard, and shaped inserts create different loading steps and visible surfaces. Custom foam box inserts give a direct reference for a shaped cavity. Coordinate the insert edges with the lid, drawer, or sleeve movement so the product does not shift into the closure.
Which print and finish choices suit the box?
Matte lamination reduces glare, while gloss lamination increases sheen on the printed surface. Offset CMYK suits detailed paperboard artwork, and digital printing suits a short run or artwork check. Soft-touch changes hand feel. Spot UV isolates a selected mark. Foil stamping, embossing, and debossing belong on flat areas away from folds, seams, glue tabs, and insert edges.
For a metal keepsake direction, embossed tin boxes show how a raised surface treatment changes the package surface. A chocolate tin box gives a compact tin reference, but the pendant cavity and chain path must be designed separately.
What dimensions should I give for a pendant box?
Write the requested size as inside length x width x depth before listing the closed outside size. Measure the pendant, chain arrangement, card, and insert in the orientation used during loading. About 1/16 in, or 1.5 mm, is a general tolerance reference to confirm against the selected board and structure.
Also record lid overlap, drawer clearance, sleeve movement, chain space, and clasp clearance. A cavity sized from the pendant alone can leave the chain loose or place the clasp under the lid. Inside measurements guide fit. Outside measurements guide display, storage, and shipping.
What should the pendant-box proof show?
The digital proof should show panel order, opening direction, scores, glue areas, insert edges, logo placement, and the intended jewelry reveal. Check bleed and safe areas before approval. Low-resolution artwork can soften small detail, while RGB artwork can shift when converted for press. Fold the structure and load the pendant before accepting a crowded score, covered mark, or tight closure.
Which product references fit this project?
The closest catalog reference is custom pendant boxes. Use the insert page, embossed tin reference, and chocolate tin reference to separate the cavity decision from the outer surface decision. The product should sit in the same orientation shown on the proof. Review the custom packaging design page when the pendant, insert, and opening direction are ready.
What should I send before a pendant-box quote?
A workable quote starts with a loaded jewelry reference and a short list of fixed choices.
- Provide the pendant, chain, clasp, backing card, and any component that shares the package.
- Label inside cavity, outside size, insert support, opening motion, and clearance needs.
- Choose rigid, magnetic flap, drawer, slide, folding carton, or tin direction.
- Mark artwork panels, print process, lamination, foil, embossing, and debossing.
- Share quantity, proof status, packing method, product reference, and destination.
Custom Packaging Lane quotes pendant boxes from a 100-unit minimum. Pricing is from $0.49 per unit at volume, quoted to spec. Production typically takes 8 to 10 business days after proof approval, plus delivery. Free US shipping, free design support, and a free dieline are available. The $19.99 sample kit is credited toward the first order.
Frequently Asked Questions
What insert works for a pendant box?
A pendant-box insert should hold the pendant in a repeatable position while leaving the intended face visible. Plan the pendant outline, chain route, clasp location, backing card, and loading direction together. Foam can create a defined cavity, while paperboard or a shaped insert creates a different support and handling step.
Should a pendant box be rigid or folding?
A rigid pendant box uses a separate base and lid, while a folding carton uses paperboard and ships flat. A magnetic flap keeps the lid attached, and a drawer or slide moves a tray through a sleeve. Compare opening motion, insert support, storage, artwork area, and jewelry reveal before choosing.
How should I measure a pendant box?
Measure the pendant, chain arrangement, card, and insert in the loading orientation. Write the requested size as inside length x width x depth, then record the closed outside size separately. About 1/16 in, or 1.5 mm, is a common tolerance reference. Confirm clearance against the selected board, insert, lid, drawer, or sleeve.
Can a pendant box use a foam insert?
A foam insert can create a defined cavity around the pendant, but it must also account for the chain route, clasp, backing card, and visible reveal. State whether the jewelry rests loose, sits in a shaped cavity, or presents against a card. The insert edges must clear the lid, drawer, or sleeve movement.
What should a pendant-box proof show?
A pendant-box proof should show the folded structure, opening direction, panel order, scores, glue areas, insert edges, logo placement, and jewelry reveal. Check bleed, safe areas, clasp clearance, and the chain path. Load the pendant before approval because a flat file can hide a covered mark, crowded fold, or tight closure.
